Suburban Water Heater Igniter Electrode 525005
The Suburban 525005 Water Heater Igniter Electrode is the OEM replacement 2-prong electrode service kit used in Suburban SW Series direct spark ignition (DSI) RV water heaters. The electrode creates the spark needed to ignite the propane burner and also helps the ignition system verify that a flame has been established.
A worn, cracked, corroded, or improperly positioned electrode can cause no-spark conditions, delayed ignition, repeated ignition attempts, burner shutdown, or a water heater that will not stay lit.
Suburban Part Number: 525005
Replaces / Supersedes: 232258
Type: 2-Prong DSI Electrode
Electrode Wire: Not Included
Fits Suburban SW Series Water Heaters
Suburban 525005 fits SW Series DSI water heaters including:
4-Gallon Models
- SW4D
- SW4DE
- SW4DEL
- SW4DEM
6-Gallon Models
- SW6D
- SW6DE
- SW6DEL
- SW6DEM
- SW6DM
- SW6DEC
- SW6DELC
10-Gallon Models
- SW10D
- SW10DE
- SW10DEL
- SW10DEM
- SW10DM
- SW10DEC
- SW10DELC
12-Gallon Models
- SW12D
- SW12DE
- SW12DEL
- SW12DEM
- SW12DEC
- SW12DELC
16-Gallon Models
- SW16D
- SW16DE
- SW16DEL
- SW16DEM
- SW16DEC
- SW16DELC
Signs of a Bad Suburban Water Heater Electrode
Common symptoms include:
- Water heater does not spark
- Burner fails to ignite
- Repeated clicking or ignition attempts
- Burner lights but shuts off shortly afterward
- Intermittent ignition
- Visible cracking or damage to the ceramic insulator
- Corrosion or deterioration of the electrode probe
Estimated Installation Time
10–20 minutes
Tools Required
- Screwdriver
- Basic hand tools
- Needle-nose pliers, if needed
Potential Issues
Before replacing the electrode, inspect the electrode wire, electrical connections, burner alignment, propane supply, ground connection, gas valve, and ignition control board. The electrode must also be properly positioned relative to the burner for a strong spark and reliable flame sensing.
Suburban 525005 replaces electrode assembly 232258 and is designed for Suburban SW Series DSI RV water heaters.
