Suburban Water Heater Burner Assembly 011030

The Suburban 011030 Water Heater Burner Assembly is an OEM replacement burner used on later-production Suburban SW Series direct spark ignition (DSI) RV water heaters. The burner mixes propane with combustion air and directs the flame into the water heater combustion chamber for proper heating.

Suburban 011030 is used with newer SW Series water heaters that also use the later-style gas valve system. Because Suburban changed burner assemblies during production, the water heater model and serial number should be checked before ordering.

Suburban Part Number: 011030
Application: Later-Production Suburban SW Series DSI Water Heaters

Fits Suburban SW Series Water Heaters

4-Gallon Models

• SW4D / SW4DE

  • Serial number 164810696 and above — Suburban 011030 is the correct burner assembly for your model

  • Serial number 164810695 and below — an earlier burner assembly is required

6-Gallon Models

• SW6D / SW6DE / SW6DEL / SW6DEM

  • Serial number 164513433 and above — Suburban 011030 is the correct burner assembly for your model

  • Serial number 164513432 and below — an earlier burner assembly is required

10-Gallon Models

• SW10D / SW10DE / SW10DEL / SW10DEM

  • Serial number 164015531 and above — Suburban 011030 is the correct burner assembly for your model

  • Serial number 164015530 and below — an earlier burner assembly is required

12-Gallon Models

• SW12D / SW12DE / SW12DEL / SW12DEM

  • Serial number 164513463 and above — Suburban 011030 is the correct burner assembly for your model

  • Serial number 164513462 and below — an earlier burner assembly is required

16-Gallon Models

• SW16D / SW16DE / SW16DEL / SW16DEM

  • Serial number 165012121 and above — Suburban 011030 is the correct burner assembly for your model

  • Serial number 165012120 and below — an earlier burner assembly is required

Additional Fitment

• Suburban SAW6 Series

Signs of a Bad or Damaged Burner Assembly

Common symptoms include:

• Uneven or unstable burner flame

• Yellow or sooty flame

• Burner will not stay lit

• Delayed ignition

• Excessive burner noise

• Visible corrosion, cracking, or deterioration

• Poor water-heater performance despite proper propane pressure

• Burner tube is obstructed or damaged

Estimated Installation Time

15–30 minutes

Tools Required

• Screwdriver

• Open-end wrenches

• Basic hand tools

• Approved propane leak detection solution

Potential Issues

Before replacing the burner assembly, inspect the burner orifice, gas valve, igniter electrode, propane pressure, air intake, combustion chamber, and burner alignment. Dirt, spider webs, rust, or debris inside the burner tube can cause poor combustion and may produce symptoms similar to a damaged burner.

The burner should be properly aligned with the gas orifice and combustion chamber. After installation, inspect the burner flame for proper operation and check any disturbed propane connections for leaks.

If your Suburban SW4, SW6, SW10, SW12, or SW16 water heater is above the applicable serial-number break listed above, Suburban 011030 is the correct OEM burner assembly for your model.
