Suburban 525022 Water Heater Thermostat / Hi-Limit Switch Cover

The Suburban 525022 Thermostat / Hi-Limit Switch Cover is the OEM protective cover used on many Suburban SW-Series RV water heaters. It installs over the thermostat and high-limit switch area to help protect the electrical components from moisture, dirt, debris, and accidental contact.

The 525022 is used on both gas-only and gas/electric SW-Series water heaters and is designed to cover the thermostat / hi-limit switch area used by both the 12V DC control circuit and the 120V AC electric heating circuit on applicable models.

Models It Fits

The Suburban 525022 fits many common SW-Series water heaters, including:

• SW4D

• SW6D

• SW6DE

• SW6DEL

• SW6DEM

• SW6DM

• SW6PE

• SW6PER

• SW10D

• SW10DE

• SW10DEL

• SW10DM

• SW10PER

• SW12D

• SW12DE

• SW12DEL

• SW12DEM

• SW16D

• SW16DE

• SW16DEL

• SW16DEM

Additional SW-Series applications may exist depending on production date and water heater configuration.

Fits Both DC and AC Thermostat / Hi-Limit Switches

The 525022 cover is used over both the DC and AC thermostat / hi-limit switch area on applicable Suburban SW water heaters.

12V DC Thermostat / Hi-Limit

The cover is used with the 12V DSI thermostat / hi-limit switch, including applications using:

• Suburban 525007

• Legacy 12V thermostat / hi-limit components used in the SW-Series control circuit

This side of the system is associated with the propane / DSI water-heater controls.

120V AC Thermostat / Hi-Limit

On gas/electric SW models, the same cover also protects the 120V electric thermostat / hi-limit switch, including:

• Suburban 525002

• Legacy 232306

This thermostat controls the 120V electric heating-element circuit.

On many gas/electric SW-Series water heaters, both the 12V DC and 120V AC thermostat / hi-limit switches are located in the same protected service area, and the 525022 cover is used to shield those components.

Replaces Older Part Number

The Suburban 525022 replaces or supersedes older cover number:

• 090562

If the original cover is marked with 090562, the 525022 is the current replacement in applicable installations.

What the 525022 Cover Does

The thermostat / hi-limit cover helps:

• Protect the thermostat and hi-limit switches

• Shield exposed electrical terminals

• Reduce exposure to moisture and debris

• Protect both 12V DC and 120V AC thermostat components on gas/electric models

• Prevent accidental contact with electrical connections

• Restore the factory-style protection after water-heater service

When You May Need a Replacement Cover

Replace the 525022 if the original cover is:

• Cracked

• Missing

• Brittle from age or heat

• Burned or distorted

• No longer staying securely in place

• Damaged during thermostat replacement

• Allowing dirt or moisture into the thermostat area

Estimated Install Time

Approximately 5–10 minutes in most applications.

Tools Required

Usually only basic hand tools are required:

• Phillips screwdriver

• Small nut driver if needed

• Basic electrical hand tools

Installation Notes

Disconnect all electrical power before servicing the water heater.

On gas/electric models, this means disconnecting both:

• 12V DC power

• 120V AC power

While the cover is removed, inspect the thermostat / hi-limit switches, wiring terminals, and surrounding area for signs of corrosion, overheating, loose connections, or water intrusion.

If any electrical terminals appear burned or damaged, correct the underlying problem before installing the new cover.

Product Specifications

Manufacturer: Suburban / Airxcel
Part Number: 525022
Legacy Part Number: 090562
Part Type: Thermostat / Hi-Limit Switch Protective Cover
Application: Suburban SW-Series RV Water Heaters
Protects: 12V DC and 120V AC thermostat / hi-limit switch area on applicable models
Common Related Parts: 525007, 525002, 232306

Important Fitment Note

The Suburban 525022 is the protective cover only. It does not include the thermostat or hi-limit switches.

For many gas/electric SW-Series water heaters, the 525022 covers the service area containing both the 12V DC thermostat / hi-limit switch and the 120V AC thermostat / hi-limit switch.
